Booking & Technical Information
| FACILITY PROFILE | ||
 |
Curtain System | YES |
| Floor Size | 18,390 sq. ft | |
| Number Fire Aisles | The fire aisles are to be at a 6 ft. minimum in the stage and house area and 4 ft. clearance from backstage. | |
| Pyrotechnics Allowed | YES (Permit and Demonstration REQUIRED). The fire aisle are a 6 ft. minimum in the stage and house area and 4 ft. clearance from backstage. | |
| BACK-STAGE ROOMS | |||||
 |
Name of Room | Size | Description | Distance From Stage | |
| Room 1 | 22' x 18' | With bathroom and shower | 70 feet – directly behind stage | ||
| Room 2 | 22' x 18' | With bathroom and shower | 70 feet – directly behind stage | ||
| Room 3 | 22' x 18' | With bathroom and shower | 70 feet – directly behind stage | ||
| Room 4 | 22' x 18' | With bathroom and shower | 70 feet – directly behind stage | ||
| Small team size rooms (4) | With 3 bathrooms and 3 showers | 90 feet – directly behind stage | |||
| Miscellaneous Information: | |||||
| Climate can be controlled for the dressing rooms; and the four "star" dressing rooms are separate from the "team" rooms. | |||||
| Furniture available. | |||||
| HOUSE EQUIPMENT | |||
 |
Equipment Name | Quantity | Description |
| Spotlights | 6 | Super Arcs Lycian - 1267 | |
| Staging | 60 pieces |
StageRight ME - 3750 (Portable); Configured up to 60 ft. x 48 ft; Size 4' x 8'; Height 4 ft. – 6 ½ ft. (Adjustment in height increments of 2 inches) |
|
| Forklifts | 2 | Mitsubishi and Caterpillar; Weight 4,000 lbs./ 5,000 lbs. | |
| LOAD-IN DOCK INFORMATION | ||
 |
Dock Information | Yes |
| Number of Trucks at a Time | One truck at a time at dock. Can load in building from two loading areas. | |
| Parking Spaces For Buses | Parking for buses is under Pratt Pavilion beside the Arena. | |
| Parking Spaces For Trucks | Parking for trucks is across the street from the west loading dock. | |
| RIGGING | ||
 |
Load Bearing Capacity | Maximum load at any single panel point is 5,000 lbs. Maximum total roof load for an event is 200,000 lbs. |
| Height to Ceiling (ft) | 120 ft. | |
| Height to High Steel (ft) | 120 ft. | |
| Height to Low Steel | 100 ft. | |
| Type of Ceiling | Open | |
| Beam Structure | 32 feet square | |
| Building Top | Flat | |
| Catwalk | Available, but rigging from catwalk is not permitted | |
| Scoreboard | Scoreboard retracts to 60 feet from floor to lower steel. The center ring of speakers surround the scoreboard are located 60 feet from floor to lower steel as well. | |
| Comments: All loads should be hung from truss panel points located interior to the four columns that support the roof structure. Panel point means where there is a vertical (straight or diagonal) that intersects one of the horizontal members of the truss.. | ||
| POWER FEED INFORMATION | |||
 |
Amps Per Feed | Phases | Distance from Upstage Center |
| 400 | 3 | 20 feet Stage Left (3 services) | |
| 600 | 3 | 20 feet Stage Right | |
| 400 | 3 |
20 feet Stage Right (2 services) |
|
| 200 | 3 |
150 feet Mid-House (2 services) |
|
| 400 | 3 |
150 feet Mid-House |
|
|
More info: |
|||
| Exterior Bus Hook-Up? | YES | Individual connections under practice facility | |
| Are services on separate transformers? | YES | Stage Left is separate from Stage Right | |
